Big bag opener
Function & Scope
Suitable for ton bag opening. Two-hand operation. Use different magnetic bar to remove the magnetic material in the dust in different applications, applying auxiliary tapping device to ensure the bag cleaning thoroughly.
Features & Benefits
|
| | ||
Eliminate dust flying, improve the cleanliness of the workshop | Reduce labor intensity and improve production efficiency | Double cartridge seal |
Specifications & Parameters
Product Model Para meters |
TB-1000-PA |
TB-1000-PB |
TB-1000-PC |
TB-1000-GA |
Conveying type |
Negative pressure |
Negative pressure |
Negative pressure |
Gravity |
Discharge method |
Rotary valve DN200 |
Rotary valve DN250 |
Vibrating Screens |
Proportional Valves |
Motor power(kw) |
0.75 |
1.5 |
0.09 |
/ |
Discharge speed (kg/min) |
50~100 |
≥100 |
0~50 |
≥200 |
